HUBA Differential pressure switch 664 series 664.903002

  • HUBA Differential pressure switch 664 series 664.903002
  • HUBA Differential pressure switch 664 series 664.903002
  • HUBA Differential pressure switch 664 series 664.903002
  • HUBA Differential pressure switch 664 series 664.903002
Herkunftsort USA
Markenname HUBA
Zertifizierung CE
Modellnummer 664.903002
Min Bestellmenge 1
Preis US$125/PC
Verpackung Informationen Karton
Lieferzeit 1 Woche
Zahlungsbedingungen L/C, D/A, D/P, T/T, Western Union
Versorgungsmaterial-Fähigkeit 500 Stück
Produktdetails
Hervorheben

HUBA differential pressure switch 664 series

,

Differential pressure gauge with warranty

,

664.903002 pressure switch industrial
Hinterlass eine Nachricht
Produkt-Beschreibung
Product feature
Pressure measuring range
-5 ... 5 mbar (Relative and difference); 0 ... 2000 mbar (Relative and difference); 0 ... 2000 mbar (Absolute); 800 ... 1200 mbar (Barometric sensor)
Response time
<2 ms
Pressure connection
Hose nozzle (Ø 4.8 mm); Plastic screw connection (Ø 3.9 mm / M6x0.75)
Sensor weight
1.5 g (additional)
Field of application
Media
Air; neutral gas
Medium temperature
-40 ... 85 °C
Permissible overload on one side
10 x FS; 3 x FS
Bursting pressure
15 x FS; 5 x FS
Ambient condition
Ambient temperature
-40 ... 85 °C
Storage temperature
-40 ... 100 °C
Material
Housing
LCP
Substrate
Ceramic Al2O3 (96 %)
Measuring element
Silicon
Adhesives
Silicone, epoxy
plastic screw fittings
PC
